YFB4 series high efficiency dust explosion-proof asynchronous motor

Brief introduction:

YFB4 series high-efficiency dust explosion-proof three-phase asynchronous motor, the

explosion-proof performance complies with GB/T 3836.1-2021 "Explosive Atmosphere Part 1:

General Requirements for Equipment" and GB/T 3836.31-2021 "Explosive Atmosphere Part

31: Ignition by Preventing Dust Shell "t" protected equipment , made into dust explosion-proof

type. It is suitable for indoors or outdoors in factories, areas 21 or 22 where dust clouds with an

ignition temperature higher than 130° C can mix with air to reach an explosive concentration,

as a general driving force. It is mainly used in chemical, pharmaceutical, textile, food, feed and

other industries, and is also widely used in metal polishing, grain storage and transportation,

papermaking, tobacco and other Industries.

The efficiency of the motor complies with Level 2 in GB18613-2020 "Limitable Values of

Energy Efficiency and Energy Efficiency Grades of Electric Motors", which is IE4 of

IEC60034-30.

The notable features of the motor are safety, energy saving, long life, small vibration, low

noise and high reliability.
