Specifications:
• NEMA: 1/3-20HP (Three Phase)
IEC: 0.06-18.5kW (Three Phase )
• NEMA: Frame 56C-256TC;
IEC: H56-H160
• 115/230V, 230/460V, 575V;
230/400V 400/690V
• Cooling Options: TEFC & TENV
• Protective Class IP69K IP67
• All stainless steel structure
• Two-barrier mechanical seal on the output shaft
• Laser marked nameplate
• Independently and seamless welded feet
• Polished stainless steel finish
Brief introduction:
Stainless steel motors designed to meet the severe sanitation requirements of food grade and high
pressure washdown motor applications in the pharmaceutical,food and beverage,processing and packaging
industries . like Dairies and milk processing , water supply , cosmetics industry.meat processing industry , all
applications in extremely wet environments.
